The design verification and model validation of prototypes through detailed and accurate inspection and measurement.
Generating 3D CAD models from an existing object using our in house precise co-ordinate measuring machine.
Providing CAD comparison with the dimensional measurements of the part or model as qualification testing.
Results of model conflict resolution can highlight corrections which will bring everything into tolerance.
Providing a 3D inspection to verify the mould or die is correct against the CAD surface model to support QA and QC.
Using IGES and STEP CAD/CAM import software allows the neutral exchange of digital CAD data.
Our ISIR provides an initial full dimensional inspection report that represents the callout on the drawing or CAD model supplied.
Our FAIR’s provide a full dimensional inspection report, that will highlight any dimensions outside the tolerance range.
EQUIPMENT
Our state of the art UKAS accredited CMM offers you one of the largest measurement cubes available in the UK today, supported by our experienced CMM team.
Quill Engineering’s dedicated, self contained, purpose built CMM Lab provides a secure, temperature controlled and dust free environment sub contract service facility.
Qualified Application Engineers here to support your business CMM requirements as an extension of your business. Offering a fast, efficient, expert service.
